Samlex STEP 10 Step Up Converter

Samlex STEP 10 Step Up Converter

Original price was: $229.70.Current price is: $183.80.

Samlex STEP 10 Step Up Converter is designed to step up from 12 VDC to 24 VDC and deliver a rated output current of 10 Amps. Non-isolated input and output. Switch mode design, CE approved. High efficiency over-current protection, over-voltage, reverse polarity protection. 6.3mm push-on flat pin connectors.

SKU: V0001-02106 Category: Brand:

Description

Samlex STEP 10 Step Up Converter DC-DC converter is designed to deliver a rated output current of 10 Amps at an actual output voltage of 25VDC +/- 0. 1V at no load. There is no isolation between the input and output circuits, the input and output have common Negative.

Samlex STEP 10 Step Up Converter Features

  • High efficiency switching regulator
  • Small size and light weight
  • Protected against overload, short circuit, reverse polarity, and high voltage and transient suppression on input side
  • Non-isolated input and output design for higher efficiency
  • Switch mode design
  • CE Approved
  • 6.3mm push-on flat pin connectors

Applications

  • Industrial
  • Commercial
  • OEM
  • Recreational
  • Marine

Specifications

  • Input: 9 – 18 VDC
  • Output: 24 VDC
  • Amps: 10 Amps
  • Weight: 0.8 LBS
  • Dimensions: 5″ x 3.5″ x 2″
  • Safety: CE
  • Warranty: 2 Year Limited

STEP 10 Manual

STEP 10 Spec Sheet

Additional information

Weight 1 lbs
Dimensions 5.5 × 3.5 × 2 in
Manufacturer Part Number

STEP 10
